38kV Siab-Power Burner Igniter nrog Ua-hauv Controller thiab 30-Second Auto Shut-Off|TW-G-ZWY02
Txhim khu kev ntseeg siab -Lub zog Ignition rau Industrial Oil Burner Systems
Cov neeg siv khoom siv roj zaub thiab cov roj pov tseg feem ntau ntsib teeb meem nyuaj thaum pib txias. Cov zis 38kV ntawm TW-G-ZWY02 pab tsim kom muaj cov nplaim taws ruaj khov sai dua, tshwj xeeb tshaj yog thaum cov roj atomization muaj tsawg dua qhov zoo tagnrho.
Engineered rau cov roj zaub burners, diesel burners, khib nyiab roj burners, thiab hnyav roj combustion tshuab, lub TW-G-ZWY02 generates mus txog 40W ntawm ignition zog thiab ib tug siab - lub zog spark muaj peev xwm ua kom tiav ignition nrug txog 8 hli. Tus tswj kev sib koom ua ke txiav tawm qhov hluav taws xob hluav taws xob tom qab 30 vib nas this, txo cov khoom hnav, txhim kho kev nyab xeeb, thiab txuas ntxiv kev pab cuam lub neej.
Featuring tag nrho epoxy resin encapsulation thiab ntxiv rwb thaiv tsev, qhov noIndustrial Igniteryog tsim los tiv thaiv kev ua haujlwm hnyav, nrog rau kev ya raws, kev co, plua plav, thiab kub hloov pauv.
Vim li cas thiaj xaiv TW-G-ZWY02?
✔ Ua - hauv Electronic Ignition Controller
✔ Tsis siv neeg 30-Qhov thib ob Auto Shut-Off Function
✔ Siab -Zoo 38kV Spark Output
✔ Muaj zog 40W Ignition Performance
✔ Txhim khu kev tiv thaiv qhov deb mus txog 8mm
✔ Tag Nrho Epoxy-Sealed Moisture-Resistant Design
✔ AC 110V thiab AC 220V Versions Muaj
✔ Haum rau kev lag luam tsis tu ncua
✔ OEM & ODM Customization Support
✔ Zoo tagnrho hloov rau Standard Ignition Transformers
High-High hluav taws xob Ignition Transformer
Dab tsi ua rau tus qauv no txawv? Cov lus teb yog tus tswj kev sib xyaw ua ke. Tsis zoo li cov pa hluav taws xob hluav taws xob hluav taws xob uas txuas ntxiv mus tas li, TW-G-ZWY02 cia li nres tom qab 30 vib nas this.
Nrog rau qhov tso zis hluav taws xob ntau dua lossis sib npaug ntawm 38kV thiab ntsuas lub zog ntawm 40W, qhov noHigh Energy Ignition Systemua rau lub txim muaj zog thiab ruaj khov uas ua kom muaj hluav taws kub ceev thaum lub sij hawm pib lub tshuab hluav taws xob. Lub siab -voltage outputs txo qhov tsis ua hauj lwm ntawm qhov hluav taws xob thiab txhim kho kev ntseeg tau ntawm lub tshuab hluav taws xob, tshwj xeeb tshaj yog nyob rau hauv cov roj zaub, cov roj pov tseg, thiab cov roj hnyav hnyav.
Ua-hauv Ignition Controller nrog 30-Pib Ob Nws Pib Kaw-Off
Kev sib xyaw ua keIgnition Control Modulecia li txiav tawm lub voj voog hluav taws xob tom qab 30 vib nas this, tiv thaiv qhov tsis tsim nyog txuas ntxiv thiab txo cov kev ntxhov siab thermal ntawm cov khoom siv hluav taws xob.
Cov txiaj ntsig muaj xws li:
Txhim khu kev ruaj ntseg ua haujlwm
Extended igniter lifespan
Txo kev siv hluav taws xob
Cov nqi kho mob qis dua
Txhim kho qhov kev cia siab ntawm burner
Cov yam ntxwv no ua rau TW-G-ZWY02 zoo tagnrhoBurner Ignition Controllerrau kev lag luam thiab cov khoom siv cua sov.
Tag Nrho Epoxy-Kev tsim kho
Sab hauv siab -voltage circuitry yog tiv thaiv tag nrho los ntawm epoxy resin encapsulation.
Qhov kev tsim vaj huam sib luag no muab:
Zoo noo noo tsis kam
Txhim khu kev vibration kuj
Txhim kho dielectric rwb thaiv tsev
Ntev - kev cia siab rau lub sij hawm nyob rau hauv kev lag luam ib puag ncig
Tus qauv tsim muaj txiaj ntsig zoo tiv thaiv cov khoom siv hluav taws xob tsis zoo los ntawm cov plua plav, roj vapor, thiab kev sib kis ntawm ib puag ncig.
Hluav Taws Xob Kev Nyab Xeeb Kev Ua Haujlwm
Lub igniter ntse dhau qhov AC 1500V / 50Hz / 1mA / 3-thib ob dielectric lub zog kuaj ntawm cov input terminals thiab vaj tsev tsis muaj flashover lossis rwb thaiv tsev tawg.
Qhov kev ua tau zoo ntawm cov rwb thaiv tsev no ua kom ntseeg tau tias muaj kev lag luam hauv kev xav tau cov ntawv thov kev lag luam thiab txhawb kev ua raws li thoob ntiaj teb ignition transformer yuav tsum muaj kev nyab xeeb.
Technical Specifications
| Parameter | Specification |
|---|---|
| Yam khoom qauv | TW-G-ZWY02 |
| Yam khoom | Burner Ignition Unit / Ignition Transformer |
| Input voltage | AC 220V / 50Hz |
| Optional Input Voltage | AC 110V / 60Hz |
| Cov zis hluav taws xob | Ntau tshaj lossis sib npaug rau 38kV |
| Rated zog | 40W |
| Kev khiav hauj lwm tam sim no | 190mA ± 15% |
| Ignition nrug | Tsawg dua los yog sib npaug li 8 hli |
| Controller Function | Ua -hauv Electronic Ignition Controller |
| Auto shut-Tawm | 30 Seconds |
| Ua haujlwm kub | -20℃~ +60 degree |
| Kev khiav dej num | 20% ~ 50% RH |
| Cia Kub | -20℃~ +80 degree |
| Cia Humidity | 15% ~ 85% RH |
| Dielectric zog | AC 1500V / 50Hz / 1mA / 3s |
| Txoj kev rwb thaiv tsev | Epoxy Resin Encapsulation |
Mechanical Dimensionsn
| Yam khoom | Specification |
|---|---|
| Ntev | 98.5mm ± 1mm |
| Dav | 73.5mm ± 1mm |
| Qhov siab | 40mm ± 1mm |
| Input Lead | Φ2.0 × 60cm ± 5cm |
| High Voltage Output Cable | Φ6.5 × 65cm ± 5cm |
Daim ntawv thov
The TW-G-ZWY02Roj Burner Spark Generatoryog dav siv nyob rau hauv:
Muaj boilers
Commercial Boilers
Zaub roj Burners
Khib Roj Burners
Diesel Burners
Heavy Oil Burners
Biomass combustion Systems
Muaj Furnaces
Cov dej kub cua sov
Chav Tsim Khoom Siv
Thermal Processing Khoom
OEM Burner Manufacturing
OEM & ODM Kev Pabcuam
Peb muab cov kev pabcuam OEM thiab ODM hloov tau yooj yim rau cov khoom siv hluav taws xob thoob ntiaj teb thiab cov chaw muag khoom cua sov.
Customization xaiv muaj xws li:
110V / 120V / 220V input voltage
Customized Lead Lengths
Tshwj xeeb Connectors thiab Terminals
Private Label Branding
Custom Packaging Solutions
FAQ
Vim li cas lub igniter kaw tom qab 30 vib nas this?
Tus maub los cia li nres ignition tom qab lub sijhawm pib. Qhov no txo cov khoom hnav thiab txhim kho kev nyab xeeb.
Nws puas tuaj yeem siv rau zaub roj burners?
Yog lawm. Lub siab - lub zog hluav taws xob tso tawm yog tsim rau cov roj zaub, roj diesel thiab cov roj khib nyiab combustion systems.
Puas yog 110V input muaj?
Yog lawm. Ob lub 110V thiab 220V versions tuaj yeem muab tau.
Tsis zoo li generic ignition transformers los ntawm ntau tus neeg muag khoom, TW-G-ZWY02 yog tsim los ntawm Jiangsu Tianwang Solar Technology thiab kuaj ua ntej xa khoom. Txhua chav nyob rau hauv kev rwb thaiv tsev thiab ignition kev ua tau zoo pov thawj los xyuas kom meej kev ruaj ntseg nyob rau hauv daim ntawv thov burner.
